PLC Control CNC H Beam Sawing Cutting Machine Line Easy Operation
Applicable industry:
Used for the sawing of H-shape steel, box beams, channel steel, angle steel and round steel of steel structure, bridge, three dimensional garages and petrol platform industries.
Product feature:
■ Double column design equipped with strong lathe bed, with fine function of absorbing vibration during high speed sawing.
■ Can rotate itself and no need to rotate for longer work piece when beveling for 0°~45°, can keep the continuity of production.
■ Saw blade driving with greater motor power and good transmission. Used for the specialized processing of various section steel of steel structure industry.
■ Saw blade hydraulic automatic tensioning device, keep saw blade stable during high speed rotation and can extend life of saw blade.
■ Small aperture, high precision, and greatly reduce material consumption.
■ Laser alignment function and advanced and retreated structure slightly adjusted with hand, convenient for cutting accurately.
■ Automatic coolant compatible with blade could make blade lubricant and reduce the temperature of blade.
■ PCL control, sawing linear velocity can be adjusted by transducer motor and sawing feeding speed also can be adjusted by hydraulic stepless adjustment. This greatly promotes production efficiency.
■ Key machine, hydraulic pressure and electric components are chosen famous products domestic and abroad.
Specifications:
|
Sawing force (mm) |
round steel: φ660 | |
| square steel: 550x550 | ||
| H beam: 1000x500 | ||
| Saw blade size (mm) | Thickness:1.6 Width:54 Length:7600 | |
| Saw blade lineal speed (m/min) | 20~80 (adjustable) | |
|
Motor power |
saw blade | 7.5kw |
| hydraulic pressure | 2.2kw | |
| rotary table | 0.04kw | |
| cooling system | 0.12kw | |
| Table height | 800mm | |
| Feeding speed | stepless feeding | |
| Rotation angle | 0°～ 45° | |
| Main clamping hydraulic motor (ml/r) | 160 | |
| Front clamping hydraulic motor (ml/r) | 160 | |
|
Overall dimension |
Width: 2600mm | |
| Length:3800mm | ||
| Height: 2600mm | ||
| Gross weight of machine | ≈6000kg | |
Sawing H beam
Saeing Round Pipe
Workpieces
