500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power

500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power
500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power

Large Image :  500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power

Product Details:
Place of Origin: China
Brand Name: Auten
Certification: ISO9001
Model Number: BP1000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 300 sets/year
Contact Now
Detailed Product Description
Max. Processing Plate Width: 1000mm Processing Plate Thickness: 2-100mm
Processing Plate Length: 100mm～∞ Min. Workpiece: 50x50x2mm
Max. Loading Capacity: 500kgs Machine Power: 28KW
Feed Motor: 2 Feeding Speed: 10～4000 Mm/min

500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power



Equipment Purpose:



Plate polishing machine is mainly used for polishing of laser cutting and plasma cutting.



Product Configuration:



No. Model BP1000
1 Max. processing plate width 1000mm
2 Processing plate thickness 2-100mm
3 Processing plate length 100mm～∞
4 Min. workpiece 50x50x2mm
5 Max. loading capacity 500kgs
6 Machine power 28KW
7 Feed motor 2
8 Feeding speed 10～4000 mm/min
9 Abrasive belt deburring slag, burrs Height less than 1.5mm
10 Cartridge dust collector 5.5KW
11 Cartridge dust collector size 1000x1000x2100mm
12 Machine dimensions 2450x1700x2150mm



500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 0



Application industries:



Electric power towers, communication towers, power fittings, steel structures, storage shelves, etc.



500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 1



Equipment features:


1. Automatic continuous feeding, unlimited length, improve production efficiency and reduce production costs.


2. CNC control is adopted, operation information and status are fed back in time, and the operation is simple.



500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 2



3. CNC PLC and touch screen control are adopted, one-button start and stop are adopted, and the operation is simple and convenient.


4. Pneumatic tensioning device, stable operation, ensures the service life of the abrasive belt.



500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 3



5. The equipment is simple and convenient to operate, safe and reliable in performance, and high in production efficiency.

500kgs Max. Loading Capacity Model BP1000 Plate Polishing Machine 28KW Machine Power 4

A plate polishing machine is primarily used for the polishing of metal plates that have been processed through laser cutting or plasma cutting methods. These machines are designed to smooth and refine the surface of the metal plates, removing any burrs, rough edges, or oxidation marks that may have resulted from the cutting processes. By providing a high-quality finish, plate polishing machines improve the aesthetic appearance of the plates and enhance their overall performance in subsequent operations or applications. This type of machinery is widely used in industries such as metal fabrication, manufacturing, and automotive, where precision and surface quality are crucial.
