Model FF80 CNC Flat Steel Clamp Machinewith Bending And Punching Functions

Large Image : Model FF80 CNC Flat Steel Clamp Machinewith Bending And Punching Functions

Product Details:

Place of Origin:	China
Brand Name:	Auten
Certification:	ISO9001
Model Number:	FF80

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Wooden case
Delivery Time:	30 days
Payment Terms:	L/C, T/T
Supply Ability:	500 sets/year

Contact Now

Detailed Product Description

Processing Width:	40-80mm	Processing Thickness:	4-8mm
Min. Diameter:	30mm	Max. Diameter:	1500mm
Max. Feeding Speed:	55m/min	Max. Bending Speed:	800°/sec
Punching Cylinder:	150*50	Feeding Servo Motor:	5.5kw/2 Unit

Model FF80 CNC Flat Steel Clamp Machinewith Bending And Punching Functions

Product Application:

Flat iron banding machine is a type of banding processing machine,suitable for traffic banding,power and photovoltaic banding, seismic brackets,etc. It supports various customized specifications and dimensions.The flat iron banding machine adopts advanced hydraulic system and servo control technology, featuring a compact structure. It is easy to operate,stable in performance, and energy-efficient.

Product Parameter Configuration Table:

Model	FF80-8
Processing width	40-80mm
Processing thickness	4-8mm
Minimum diameter	30mm
Maximum diameter	1500mm
Maximum feeding speed	55m/min
Maximum bending speed	800°/sec
Punching cylinder	150*50
Feeding servo motor	7.5kw/1 unit
Cut-off cylinder	150*50
Bending servo motor	5.5kw/2 units
Hydraulic system	Huade
Telescopic servo motor	1kw
Electrical control system	Weichuang / Xinjie
Hydraulic power station motor	15kw
Mold Material	DC53
Feed Roller Material	Cr12MoV
Dimensions	3.2×2.2×1.8m
