Application Industry:

Primarily designed for machining the inner arc surfaces of angle steel profiles.

Product Parameters:




Workpiece process

1. Load the angle steel workpiece into the designated machining area of the equipment.

2. Select the automatic operating mode and press the cycle start button. The machine will then automatically execute the complete programmed machining sequence.

3. Angle steel components of identical specifications can be continuously processed, maximizing production throughput while maintaining consistent and stable batch-processing quality.


Equipment usage instructions and Characteristics

1. The equipment employs advanced high-speed milling technology for angle steel back-face machining and root-edge preparation, providing efficient, precise, and consistent processing performance.

2. Compared with conventional planing methods, the machine significantly improves root-cleaning productivity, achieving processing efficiency of up to ten times that of traditional equipment.

3. The system features an operator-oriented control design with simplified operating procedures, minimizing training requirements and reducing dependence on specialized technical skills.

4. With a highly automated operating configuration, the equipment substantially reduces manual intervention and supports continuous feeding of angle steel, enabling uninterrupted and efficient production.

5. In contrast to conventional planing machines, which are restricted by workpiece length and dedicated fixture requirements, this advanced milling solution offers enhanced processing flexibility. The elimination of specialized clamping fixtures simplifies operating procedures, improves machining efficiency, and provides greater production convenience.

6. The machine incorporates an intuitive control interface, flexible process-parameter adjustment functions, and a robust mechanical structure, ensuring stable, reliable, and consistent performance during continuous industrial operation.


Configurations:

1. The automatic continuous feeding system is driven by a high-performance geared motor, ensuring smooth, stable, and reliable material transportation while significantly enhancing overall production efficiency.

2. Key electrical components are sourced from internationally recognized manufacturers, including Schneider and Omron, ensuring excellent component quality, reliable operating performance, and extended service life.

3. The machine features a dual-spindle configuration that effectively distributes the cutting load between two cutters, reducing the load on each individual tool, extending cutter service life, and improving overall machining productivity.

4. The spindle system is powered by two 3 kW motors and incorporates precision synchronous belt transmission technology to effectively suppress vibration, providing smooth operation, excellent machining stability, and dependable long-term performance.

5. An integrated cutting-fluid cooling system provides efficient cooling and lubrication throughout the machining process, helping extend cutter service life while maintaining stable cutting conditions and achieving high-quality surface finishes.


The equipment is specifically designed for precision back milling of angle steel, enabling accurate and efficient machining of structural angle profiles. It produces finished components with excellent surface quality, precise dimensional tolerances, and clean edge geometry, making them suitable for structural fabrication and a broad range of industrial applications. The demonstration samples produced by the machine clearly showcase its high machining accuracy, consistent processing quality, and ability to generate complex back-milling profiles, providing customers and inspection personnel with a practical reference for evaluating the equipment's manufacturing capabilities and suitability for production applications.

In ultra-high-voltage (UHV) power transmission projects, where transmission towers are required to withstand demanding environmental conditions and significant structural loads, this equipment plays an important role in manufacturing the angle steel members that form the primary structural framework of the towers. It efficiently performs high-precision drilling and punching operations on angle steel components used for tower bodies, cross-arms, and other critical structural assemblies, ensuring accurate hole positioning and reliable connection quality. Consequently, the equipment contributes significantly to improving the structural strength, operational stability, and long-term service reliability of transmission towers throughout their service life.
